Misting Nozzle Charts
Misting Nozzle Size Chart
| Nozzle Size |
Flow |
Operating Pressure Range (psi) |
| Orifice |
Flow rate |
362 |
435 |
507 |
580 |
652 |
725 |
797 |
870 |
942 |
1015 |
0.15 mm
(0.006″) |
L/min |
0.03 |
0.033 |
0.036 |
0.038 |
0.04 |
0.043 |
0.045 |
0.047 |
0.049 |
0.05 |
| US gpm |
0.008 |
0.009 |
0.009 |
0.01 |
0.011 |
0.011 |
0.012 |
0.012 |
0.013 |
0.013 |
0.20 mm
(0.008″) |
L/min |
0.04 |
0.044 |
0.048 |
0.051 |
0.054 |
0.057 |
0.06 |
0.062 |
0.065 |
0.068 |
| US gpm |
0.011 |
0.012 |
0.013 |
0.013 |
0.014 |
0.015 |
0.016 |
0.017 |
0.017 |
0.018 |
0.30 mm
(0.012″) |
L/min |
0.068 |
0.075 |
0.081 |
0.086 |
0.091 |
0.096 |
0.101 |
0.105 |
0.11 |
0.114 |
| US gpm |
0.018 |
0.02 |
0.021 |
0.023 |
0.024 |
0.025 |
0.027 |
0.028 |
0.029 |
0.03 |
0.40 mm
(0.016″) |
L/min |
0.104 |
0.113 |
0.123 |
0.131 |
0.139 |
0.146 |
0.154 |
0.16 |
0.167 |
0.173 |
| US gpm |
0.027 |
0.03 |
0.032 |
0.035 |
0.037 |
0.039 |
0.041 |
0.042 |
0.044 |
0.046 |
0.50 mm
(0.020″) |
L/min |
0.114 |
0.125 |
0.135 |
0.144 |
0.153 |
0.161 |
0.169 |
0.176 |
0.183 |
0.19 |
| US gpm |
0.03 |
0.033 |
0.036 |
0.038 |
0.04 |
0.043 |
0.045 |
0.047 |
0.048 |
0.05 |
0.60 mm
(0.024″) |
L/min |
0.138 |
0.152 |
0.164 |
0.175 |
0.186 |
0.196 |
0.205 |
0.215 |
0.223 |
0.232 |
| US gpm |
0.037 |
0.04 |
0.043 |
0.046 |
0.049 |
0.052 |
0.054 |
0.057 |
0.059 |
0.061 |
0.80 mm
(0.032″) |
L/min |
0.165 |
0.181 |
0.195 |
0.209 |
0.221 |
0.233 |
0.245 |
0.256 |
0.266 |
0.276 |
| US gpm |
0.044 |
0.048 |
0.052 |
0.055 |
0.058 |
0.062 |
0.065 |
0.068 |
0.07 |
0.073 |
1.00 mm
(0.040″) |
L/min |
0.188 |
0.206 |
0.222 |
0.237 |
0.251 |
0.264 |
0.276 |
0.287 |
0.298 |
0.308 |
| US gpm |
0.05 |
0.054 |
0.059 |
0.063 |
0.067 |
0.07 |
0.073 |
0.076 |
0.079 |
0.081 |
1.20 mm
(0.048″) |
L/min |
0.207 |
0.227 |
0.245 |
0.262 |
0.278 |
0.293 |
0.307 |
0.32 |
0.332 |
0.343 |
| US gpm |
0.054 |
0.06 |
0.065 |
0.069 |
0.073 |
0.077 |
0.081 |
0.085 |
0.088 |
0.091 |
Misting Nozzle Spray Angle
All nozzles were tested at 1,000 psi using water at 70℉ (21.1℃). The room humidity was between 40-50% during the tests. The patternation measurements were conducted using the SETscan OP600 patternator that can measure sprays up to a maximum diameter of 7″.
| Orifice |
Contour based angle |
| 0.10 / .004″ |
19.90° |
| 0.15 / .006″ |
55.70° |
| 0.20 / .008″ |
72.50° |
| 0.30 / .012″ |
74.60° |
| 0.40 / .016″ |
82.00° |
| 0.50 / .020″ |
72.50° |
| 0.60 / .024″ |
91.00° |
| 0.80 / .032″ |
105.80° |
| 1.00 / .040″ |
106.90° |
| 1.20 / .048″ |
114.00° |
